M12 Round Plug Connector Open Ended Wire (Shielded) 90° Female 913281
913281
Price
--Select Configuration
Select a variant to see stock and add this item to your cart.
Lead Time available on request
Request Quote
For bulk quantities, custom cable lengths, or project pricing.
M12 A-coded 5-pole female connector with a 90° angled body and open-ended wire interface is designed for compact routing in machine wiring layouts. Shielded construction improves EMC performance by reducing susceptibility to EMI/RFI noise, which is beneficial for stable sensor and actuator signals near drives, motors, and switching equipment.
Poles 5
Coding A
Gender Female
Direction 90°
Protection IP67
Current 4
Voltage 125 V AC/DC
Shielding Yes
LED No
Specifications
| Specification | Value |
|---|---|
| Poles | 5 |
| Coding | A |
| Gender | Female |
| Direction | 90° |
| Protection | IP67 |
| Current | 4 |
| Voltage | 125 V AC/DC |
| Shielding | Yes |
| LED | No |
| Lengths | 150, 300, 500, 1000 |
Technical Resources
No verified file is available online for this product. Use the RFQ form for technical-document requests.
